Descripción del producto
Wentylator kanałowy przeznaczony do montażu w dowolnej pozycji w prostokątnych kanałach wentylacyjnych. Seria wentylatorów ILT/ILB znajduje zastosowanie w różnorodnych instalacjach wentylacji mechanicznej.
Zastosowanie
Seria wentylatorów ILT/ILB znajduje zastosowanie w różnorodnych instalacjach wentylacji mechanicznej.Przykładowe zastosowanie: wentylacja wywiewna i nawiewna mieszkań, biur, sklepów, barów, kawiarni, restauracji.
Konstrukcja
Wentylator kanałowy przeznaczony do montażu w dowolnej pozycji w prostokątnych kanałach wentylacyjnych. Obudowa z galwanizowanej blachy stalowej.Wirnik z łopatkami pochylonymi do przodu z galwanizowanej blachy stalowej, wyważony dynamicznie zgodnie z normą ISO 1940. Standardowo są wyposażone w puszkę przyłączeniową na przewodzie o dł. 800 mm.
Silnik elektryczny
Asynchroniczny trójfazowy 230/400V 50 Hz lub jednofazowy 230V 50 Hz. Stopień ochrony IP55, klasa izolacji F.Silniki posiadają termiczne zabezpieczenie uzwojenia przed przeciążeniem i są przystosowane do regulacji prędkości obrotowej.
