in line duct-fan CVAB / CVAT

Datos del producto

Fabricante:
Venture
Categoría:
Aficionados
https://www.venture.pl
Facebook
YouTube
Compartir

Descripción del producto

APPLICATION
Very quiet operation makes CVAB/CVAT ideal for ventilation of public buildings,
libraries, conference rooms, offices, restaurants, classrooms, audio studios,
etc.
CONSTRUCTION
Radial fan designed for horizontal installation in circular ventilation ducts from
Ø250 to Ø710 mm. Housing made of aluminium, acoustically insulated with 25
mm fireproof glass fiber. Impeller with aluminium backward blades (CVAB-N)
or steel sheet (CVAT-N). Fans can work in temperatures. -400 C to +600 C (CVAB-N)
 or -200 C to +400 C (CVAT-N).
MOTOR
Three-phase 230/400V 50Hz or single-phase 230V 50Hz with IP55 protection
and insulation class F. Motors provide thermal overload protection.
Speed of three-phase motor rotation (CVAT-N) is regulated by the inventer,
single-phase motor (CVAB-N) is regulated by current-voltage regulator.

BIM/CAD

Autocad

.dwg
